Model
SZ173BHANDLES
MODEL
SZ173B outward-opening handle for aluminium windows
SZ173B is an outward-opening handle for aluminium window hardware. Select it by opening direction, profile groove and the lock box or transmission set it will operate.
AT A GLANCE
SZ173B at a glance
Review the model, operating reference, dimensions and load information before confirming a final configuration.
Handle type
Outward-openingApplication
Aluminium outward casement windowsTECHNICAL DRAWING
Complete technical drawing
No separate model drawing is published for this catalogue handle. The product image identifies the model; project-specific dimensions and matching drawings can be supplied after the window system is confirmed.
SPECIFICATIONS
Specifications
Model, application, size, load and adjustment references for SZ173B.
Model
SZ173B
Component
outward-opening handle
Application
Aluminium outward casement windows
Selection reference
Opening direction, profile groove and matching lock box or transmission set
CONFIGURATION
What to confirm
Use these references to select a compatible SZ173B hardware set.
Opening direction
Outward-opening window
Profile & groove
Provide the profile section or groove dimensions so the handle interface can be checked
Lock box pairing
Confirm the spindle, lock box and transmission relationship as a complete set
Finish & quantity
State finish, required quantity and destination country
REQUEST MATCHING
Match SZ173B to your window system
Send a SZ173B reference, profile drawing or site photo to start the matching review.
- Model or existing hardware
- Profile and opening type
- Sash weight and quantity
