Model
JSFZ02AHANDLES
MODEL
JSFZ02A window handle for aluminium windows
JSFZ02A is a window handle shown in the aluminium hardware catalogue. Confirm the handle position, spindle interface and matching lock box with the window system before selection.
AT A GLANCE
JSFZ02A at a glance
Review the model, operating reference, dimensions and load information before confirming a final configuration.
Component
Window handleApplication
Aluminium window hardwareTECHNICAL DRAWING
Complete technical drawing
No separate model drawing is published for this catalogue handle. The product image identifies the model; project-specific dimensions and matching drawings can be supplied after the window system is confirmed.
SPECIFICATIONS
Specifications
Model, application, size, load and adjustment references for JSFZ02A.
Model
JSFZ02A
Component
window handle
Application
Aluminium window hardware
Selection reference
Opening direction, profile groove and matching lock box or transmission set
CONFIGURATION
What to confirm
Use these references to select a compatible JSFZ02A hardware set.
Opening direction
Confirm from the window system
Profile & groove
Provide the profile section or groove dimensions so the handle interface can be checked
Lock box pairing
Confirm the spindle, lock box and transmission relationship as a complete set
Finish & quantity
State finish, required quantity and destination country
REQUEST MATCHING
Match JSFZ02A to your window system
Send a JSFZ02A reference, profile drawing or site photo to start the matching review.
- Model or existing hardware
- Profile and opening type
- Sash weight and quantity
