Model
HPR14FRICTION STAYS
MODEL
HPR14 friction stay for aluminium windows
HPR14 is a friction stay listed for aluminium window hardware. Confirm the opening type, stay length, profile and sash weight for the required configuration.
AT A GLANCE
HPR14 at a glance
Review the model, operating reference, dimensions and load information before confirming a final configuration.
Component
Friction stayApplication
Aluminium window hardwareTECHNICAL DRAWING
Complete technical drawing
No separate model drawing is published for this catalogue friction stay. The product image identifies the model; project-specific dimensions and matching drawings can be supplied after the window system is confirmed.
SPECIFICATIONS
Specifications
Model, application, size, load and adjustment references for HPR14.
Model
HPR14
Component
friction stay
Application
Aluminium window hardware
Selection reference
Opening type, stay length, profile and sash weight
CONFIGURATION
What to confirm
Use these references to select a compatible HPR14 hardware set.
Opening type
Confirm outward, inward or another supported opening configuration
Stay length & position
Provide the existing stay length and installation position
Profile & sash weight
Share the profile section, sash size and estimated weight
Quantity & handing
State the required quantity and left/right arrangement where applicable
REQUEST MATCHING
Match HPR14 to your window system
Send a HPR14 reference, profile drawing or site photo to start the matching review.
- Model or existing hardware
- Profile and opening type
- Sash weight and quantity
