HP22FRICTION STAYS
MODEL
HP22 friction stay for aluminium windows
HP22 is a friction stay for 50-series outward-opening aluminium windows, with a catalogue sash-weight reference of 30–42 kg.
AT A GLANCE
HP22 at a glance
Review the model, operating reference, dimensions and load information before confirming a final configuration.
Window type
50-series outward casementMax. sash weight
30–42 kgTECHNICAL DRAWING
Complete technical drawing
No separate model drawing is published for this catalogue friction stay. The product image identifies the model; project-specific dimensions and matching drawings can be supplied after the window system is confirmed.
SPECIFICATIONS
Specifications
Model, application, size, load and adjustment references for HP22.
Model
HP22
Component
friction stay
Application
50-series outward casement
Selection reference
Opening type, stay length, profile and sash weight
CONFIGURATION
What to confirm
Use these references to select a compatible HP22 hardware set.
Opening type
Confirm outward, inward or another supported opening configuration
Stay length & position
Provide the existing stay length and installation position
Profile & sash weight
Share the profile section, sash size and estimated weight
Quantity & handing
State the required quantity and left/right arrangement where applicable
REQUEST MATCHING
Match HP22 to your window system
Send a HP22 reference, profile drawing or site photo to start the matching review.
- Model or existing hardware
- Profile and opening type
- Sash weight and quantity
